JMeter笔记11 | JMeter事务

(11 | JMeter事务),,,,,,,

(11 | JMeter事务)

• 性能测试比较关注TPS，而TPS代表每秒事务数；
• 每个事务对应的是每个请求；
• JMeter把每个请求统计成一个事务；
• JMeter也可以把多个操作统计成一个事务，可通过逻辑控制器中的事务控制器来完成。

• 逻辑控制器从字面理解就是控制程序的逻辑；
• JMeter逻辑控制器有很多个，本文主要用到的是事务控制器；
• JMeter逻辑控制器如下：

参数	说明
名称	随意设置具有业务含义即可
注释	随意设置，可为空
Generate parent sample	1、若事务控制器下有多个请求，勾选后在“查看结果树”中可同时看到事务控制器和每个取样器（请求）；2、是否控制器的成功取决于子事务是否成功；3、任何一个失败代表整个事务失败
Include duration of timer and pre-post processors in generated sample	是否包括定时器、预处理和后期处理延迟的时间

• 在JMeter笔记10 | JMeter检查点基础上我们添加事务控制器；
• 控制器添加在线程组下。

• 在线程组“禅道接口”下添加事务控制器，如下：

• 直接运行脚本，发现“查看结果树”中没有事务控制器的显示

• 勾选Generate parent sample，运行脚本，发现“查看结果树”中有事务控制器的显示；
• 从上图中为什么事务控制器是成功的，因为它下边没有任何取样器。

• 我们把之前脚本中的“1-获取token”和“1-1-获取用户列表”拖放到事务控制器下；
• 运行后发现，事务控制器是成功的，且下边的取样器也可以看到。

• 我们再把“2-创建用户”这个失败的请求放到事务控制器下，再次运行，会发现事务是失败的，那就满足规则“事务控制器下任何一个取样器失败，则整个事务失败”

<?xml version="1.0" encoding="UTF-8"?>
<jmeterTestPlan version="1.2" properties="5.0" jmeter="5.3">
 <hashTree>
 <TestPlan guiclass="TestPlanGui" testclass="TestPlan" testname="测试计划" enabled="true">
 <stringProp name="TestPlan.comments"></stringProp>
 <boolProp name="TestPlan.functional_mode">false</boolProp>
 <boolProp name="TestPlan.tearDown_on_shutdown">true</boolProp>
 <boolProp name="TestPlan.serialize_threadgroups">false</boolProp>
 <elementProp name="TestPlan.user_defined_variables" elementType="Arguments" guiclass="ArgumentsPanel" testclass="Arguments" testname="用户定义的变量" enabled="true">
 <collectionProp name="Arguments.arguments">
 <elementProp name="COMMON" elementType="Argument">
 <stringProp name="Argument.name">COMMON</stringProp>
 <stringProp name="Argument.value">/zentao/api.php/v1</stringProp>
 <stringProp name="Argument.metadata">=</stringProp>
 </elementProp>
 </collectionProp>
 </elementProp>
 <stringProp name="TestPlan.user_define_classpath"></stringProp>
 </TestPlan>
 <hashTree>
 <HeaderManager guiclass="HeaderPanel" testclass="HeaderManager" testname="HTTP信息头管理器" enabled="true">
 <collectionProp name="HeaderManager.headers">
 <elementProp name="" elementType="Header">
 <stringProp name="Header.name">Content-Type</stringProp>
 <stringProp name="Header.value">application/json</stringProp>
 </elementProp>
 </collectionProp>
 </HeaderManager>
 <hashTree/>
 <ConfigTestElement guiclass="HttpDefaultsGui" testclass="ConfigTestElement" testname="HTTP请求默认值" enabled="true">
 <elementProp name="HTTPsampler.Arguments" elementType="Arguments" guiclass="HTTPArgumentsPanel" testclass="Arguments" testname="用户定义的变量" enabled="true">
 <collectionProp name="Arguments.arguments"/>
 </elementProp>
 <stringProp name="HTTPSampler.domain">127.0.0.1</stringProp>
 <stringProp name="HTTPSampler.port">80</stringProp>
 <stringProp name="HTTPSampler.protocol">http</stringProp>
 <stringProp name="HTTPSampler.contentEncoding">UTF-8</stringProp>
 <stringProp name="HTTPSampler.path"></stringProp>
 <stringProp name="HTTPSampler.concurrentPool">6</stringProp>
 <stringProp name="HTTPSampler.connect_timeout"></stringProp>
 <stringProp name="HTTPSampler.response_timeout"></stringProp>
 </ConfigTestElement>
 <hashTree/>
 <ThreadGroup guiclass="ThreadGroupGui" testclass="ThreadGroup" testname="禅道接口" enabled="true">
 <stringProp name="ThreadGroup.on_sample_error">continue</stringProp>
 <elementProp name="ThreadGroup.main_controller" elementType="LoopController" guiclass="LoopControlPanel" testclass="LoopController" testname="循环控制器" enabled="true">
 <boolProp name="LoopController.continue_forever">false</boolProp>
 <stringProp name="LoopController.loops">1</stringProp>
 </elementProp>
 <stringProp name="ThreadGroup.num_threads">1</stringProp>
 <stringProp name="ThreadGroup.ramp_time">1</stringProp>
 <boolProp name="ThreadGroup.scheduler">false</boolProp>
 <stringProp name="ThreadGroup.duration"></stringProp>
 <stringProp name="ThreadGroup.delay"></stringProp>
 <boolProp name="ThreadGroup.same_user_on_next_iteration">true</boolProp>
 </ThreadGroup>
 <hashTree>
 <TransactionController guiclass="TransactionControllerGui" testclass="TransactionController" testname="事务控制器" enabled="true">
 <boolProp name="TransactionController.includeTimers">false</boolProp>
 <boolProp name="TransactionController.parent">true</boolProp>
 </TransactionController>
 <hashTree>
 <HTTPSamplerProxy guiclass="HttpTestSampleGui" testclass="HTTPSamplerProxy" testname="1-获取token" enabled="true">
 <boolProp name="HTTPSampler.postBodyRaw">true</boolProp>
 <elementProp name="HTTPsampler.Arguments" elementType="Arguments">
 <collectionProp name="Arguments.arguments">
 <elementProp name="" elementType="HTTPArgument">
 <boolProp name="HTTPArgument.always_encode">false</boolProp>
 <stringProp name="Argument.value">{&quot;account&quot;: &quot;admin&quot;, &quot;password&quot;: &quot;123456&quot;}</stringProp>
 <stringProp name="Argument.metadata">=</stringProp>
 </elementProp>
 </collectionProp>
 </elementProp>
 <stringProp name="HTTPSampler.domain"></stringProp>
 <stringProp name="HTTPSampler.port"></stringProp>
 <stringProp name="HTTPSampler.protocol"></stringProp>
 <stringProp name="HTTPSampler.contentEncoding">UTF-8</stringProp>
 <stringProp name="HTTPSampler.path">/${COMMON}/tokens</stringProp>
 <stringProp name="HTTPSampler.method">POST</stringProp>
 <boolProp name="HTTPSampler.follow_redirects">true</boolProp>
 <boolProp name="HTTPSampler.auto_redirects">false</boolProp>
 <boolProp name="HTTPSampler.use_keepalive">true</boolProp>
 <boolProp name="HTTPSampler.DO_MULTIPART_POST">false</boolProp>
 <stringProp name="HTTPSampler.embedded_url_re"></stringProp>
 <stringProp name="HTTPSampler.connect_timeout"></stringProp>
 <stringProp name="HTTPSampler.response_timeout"></stringProp>
 </HTTPSamplerProxy>
 <hashTree>
 <JSONPostProcessor guiclass="JSONPostProcessorGui" testclass="JSONPostProcessor" testname="JSON提取器-提取返回的token" enabled="false">
 <stringProp name="JSONPostProcessor.referenceNames">token</stringProp>
 <stringProp name="JSONPostProcessor.jsonPathExprs">$.token</stringProp>
 <stringProp name="JSONPostProcessor.match_numbers">1</stringProp>
 <stringProp name="JSONPostProcessor.defaultValues">无</stringProp>
 </JSONPostProcessor>
 <hashTree/>
 <RegexExtractor guiclass="RegexExtractorGui" testclass="RegexExtractor" testname="正则表达式提取器" enabled="true">
 <stringProp name="RegexExtractor.useHeaders">false</stringProp>
 <stringProp name="RegexExtractor.refname">token</stringProp>
 <stringProp name="RegexExtractor.regex">&quot;token&quot;:&quot;(.*?)&quot;</stringProp>
 <stringProp name="RegexExtractor.template">$1$</stringProp>
 <stringProp name="RegexExtractor.default"></stringProp>
 <stringProp name="RegexExtractor.match_number">1</stringProp>
 </RegexExtractor>
 <hashTree/>
 <ResponseAssertion guiclass="AssertionGui" testclass="ResponseAssertion" testname="响应断言-响应代码" enabled="true">
 <collectionProp name="Asserion.test_strings">
 <stringProp name="49587">201</stringProp>
 </collectionProp>
 <stringProp name="Assertion.custom_message"></stringProp>
 <stringProp name="Assertion.test_field">Assertion.response_code</stringProp>
 <boolProp name="Assertion.assume_success">false</boolProp>
 <intProp name="Assertion.test_type">2</intProp>
 </ResponseAssertion>
 <hashTree/>
 </hashTree>
 <HTTPSamplerProxy guiclass="HttpTestSampleGui" testclass="HTTPSamplerProxy" testname="1-1-获取用户列表" enabled="true">
 <boolProp name="HTTPSampler.postBodyRaw">true</boolProp>
 <elementProp name="HTTPsampler.Arguments" elementType="Arguments">
 <collectionProp name="Arguments.arguments">
 <elementProp name="" elementType="HTTPArgument">
 <boolProp name="HTTPArgument.always_encode">false</boolProp>
 <stringProp name="Argument.value">{&quot;page&quot;: 1,&quot;limit&quot;: 20}</stringProp>
 <stringProp name="Argument.metadata">=</stringProp>
 </elementProp>
 </collectionProp>
 </elementProp>
 <stringProp name="HTTPSampler.domain"></stringProp>
 <stringProp name="HTTPSampler.port"></stringProp>
 <stringProp name="HTTPSampler.protocol"></stringProp>
 <stringProp name="HTTPSampler.contentEncoding"></stringProp>
 <stringProp name="HTTPSampler.path">/${COMMON}/users</stringProp>
 <stringProp name="HTTPSampler.method">GET</stringProp>
 <boolProp name="HTTPSampler.follow_redirects">true</boolProp>
 <boolProp name="HTTPSampler.auto_redirects">false</boolProp>
 <boolProp name="HTTPSampler.use_keepalive">true</boolProp>
 <boolProp name="HTTPSampler.DO_MULTIPART_POST">false</boolProp>
 <stringProp name="HTTPSampler.embedded_url_re"></stringProp>
 <stringProp name="HTTPSampler.connect_timeout"></stringProp>
 <stringProp name="HTTPSampler.response_timeout"></stringProp>
 </HTTPSamplerProxy>
 <hashTree>
 <HeaderManager guiclass="HeaderPanel" testclass="HeaderManager" testname="保持登陆会话" enabled="true">
 <collectionProp name="HeaderManager.headers">
 <elementProp name="" elementType="Header">
 <stringProp name="Header.name">token</stringProp>
 <stringProp name="Header.value">${token}</stringProp>
 </elementProp>
 </collectionProp>
 </HeaderManager>
 <hashTree/>
 <ResponseAssertion guiclass="AssertionGui" testclass="ResponseAssertion" testname="响应断言-响应文本" enabled="true">
 <collectionProp name="Asserion.test_strings">
 <stringProp name="-1677599864">&quot;page&quot;:1</stringProp>
 </collectionProp>
 <stringProp name="Assertion.custom_message"></stringProp>
 <stringProp name="Assertion.test_field">Assertion.response_data</stringProp>
 <boolProp name="Assertion.assume_success">false</boolProp>
 <intProp name="Assertion.test_type">2</intProp>
 </ResponseAssertion>
 <hashTree/>
 </hashTree>
 <HTTPSamplerProxy guiclass="HttpTestSampleGui" testclass="HTTPSamplerProxy" testname="2-创建用户" enabled="true">
 <boolProp name="HTTPSampler.postBodyRaw">true</boolProp>
 <elementProp name="HTTPsampler.Arguments" elementType="Arguments">
 <collectionProp name="Arguments.arguments">
 <elementProp name="" elementType="HTTPArgument">
 <boolProp name="HTTPArgument.always_encode">false</boolProp>
 <stringProp name="Argument.value">{&quot;account&quot;: &quot;${account}&quot;, &quot;password&quot;: &quot;${password}&quot;, &quot;realname&quot;: &quot;测试用户&quot;}</stringProp>
 <stringProp name="Argument.metadata">=</stringProp>
 </elementProp>
 </collectionProp>
 </elementProp>
 <stringProp name="HTTPSampler.domain"></stringProp>
 <stringProp name="HTTPSampler.port"></stringProp>
 <stringProp name="HTTPSampler.protocol"></stringProp>
 <stringProp name="HTTPSampler.contentEncoding">UTF-8</stringProp>
 <stringProp name="HTTPSampler.path">/${COMMON}/users</stringProp>
 <stringProp name="HTTPSampler.method">POST</stringProp>
 <boolProp name="HTTPSampler.follow_redirects">true</boolProp>
 <boolProp name="HTTPSampler.auto_redirects">false</boolProp>
 <boolProp name="HTTPSampler.use_keepalive">true</boolProp>
 <boolProp name="HTTPSampler.DO_MULTIPART_POST">false</boolProp>
 <stringProp name="HTTPSampler.embedded_url_re"></stringProp>
 <stringProp name="HTTPSampler.connect_timeout"></stringProp>
 <stringProp name="HTTPSampler.response_timeout"></stringProp>
 </HTTPSamplerProxy>
 <hashTree>
 <HeaderManager guiclass="HeaderPanel" testclass="HeaderManager" testname="保持登陆会话" enabled="true">
 <collectionProp name="HeaderManager.headers">
 <elementProp name="" elementType="Header">
 <stringProp name="Header.name">token</stringProp>
 <stringProp name="Header.value">${token}</stringProp>
 </elementProp>
 </collectionProp>
 </HeaderManager>
 <hashTree/>
 <CSVDataSet guiclass="TestBeanGUI" testclass="CSVDataSet" testname="CSV 数据文件设置" enabled="true">
 <stringProp name="filename">D:/A_jmeter_test/create_user.txt</stringProp>
 <stringProp name="fileEncoding">UTF-8</stringProp>
 <stringProp name="variableNames">account,password</stringProp>
 <boolProp name="ignoreFirstLine">true</boolProp>
 <stringProp name="delimiter">,</stringProp>
 <boolProp name="quotedData">false</boolProp>
 <boolProp name="recycle">true</boolProp>
 <boolProp name="stopThread">false</boolProp>
 <stringProp name="shareMode">shareMode.all</stringProp>
 </CSVDataSet>
 <hashTree/>
 <JSONPostProcessor guiclass="JSONPostProcessorGui" testclass="JSONPostProcessor" testname="JSON提取器" enabled="true">
 <stringProp name="JSONPostProcessor.referenceNames">id</stringProp>
 <stringProp name="JSONPostProcessor.jsonPathExprs">$.id</stringProp>
 <stringProp name="JSONPostProcessor.match_numbers">1</stringProp>
 <stringProp name="JSONPostProcessor.defaultValues">NULL</stringProp>
 </JSONPostProcessor>
 <hashTree/>
 </hashTree>
 </hashTree>
 <HTTPSamplerProxy guiclass="HttpTestSampleGui" testclass="HTTPSamplerProxy" testname="3-删除用户" enabled="true">
 <elementProp name="HTTPsampler.Arguments" elementType="Arguments" guiclass="HTTPArgumentsPanel" testclass="Arguments" testname="用户定义的变量" enabled="true">
 <collectionProp name="Arguments.arguments"/>
 </elementProp>
 <stringProp name="HTTPSampler.domain"></stringProp>
 <stringProp name="HTTPSampler.port"></stringProp>
 <stringProp name="HTTPSampler.protocol"></stringProp>
 <stringProp name="HTTPSampler.contentEncoding">UTF-8</stringProp>
 <stringProp name="HTTPSampler.path">/${COMMON}/users/${id}</stringProp>
 <stringProp name="HTTPSampler.method">DELETE</stringProp>
 <boolProp name="HTTPSampler.follow_redirects">true</boolProp>
 <boolProp name="HTTPSampler.auto_redirects">false</boolProp>
 <boolProp name="HTTPSampler.use_keepalive">true</boolProp>
 <boolProp name="HTTPSampler.DO_MULTIPART_POST">false</boolProp>
 <stringProp name="HTTPSampler.embedded_url_re"></stringProp>
 <stringProp name="HTTPSampler.connect_timeout"></stringProp>
 <stringProp name="HTTPSampler.response_timeout"></stringProp>
 </HTTPSamplerProxy>
 <hashTree>
 <HeaderManager guiclass="HeaderPanel" testclass="HeaderManager" testname="保持登陆会话" enabled="true">
 <collectionProp name="HeaderManager.headers">
 <elementProp name="" elementType="Header">
 <stringProp name="Header.name">token</stringProp>
 <stringProp name="Header.value">${token}</stringProp>
 </elementProp>
 </collectionProp>
 </HeaderManager>
 <hashTree/>
 </hashTree>
 </hashTree>
 <ResultCollector guiclass="ViewResultsFullVisualizer" testclass="ResultCollector" testname="察看结果树" enabled="true">
 <boolProp name="ResultCollector.error_logging">false</boolProp>
 <objProp>
 <name>saveConfig</name>
 <value class="SampleSaveConfiguration">
 <time>true</time>
 <latency>true</latency>
 <timestamp>true</timestamp>
 <success>true</success>
 <label>true</label>
 <code>true</code>
 <message>true</message>
 <threadName>true</threadName>
 <dataType>true</dataType>
 <encoding>false</encoding>
 <assertions>true</assertions>
 <subresults>true</subresults>
 <responseData>false</responseData>
 <samplerData>false</samplerData>
 <xml>false</xml>
 <fieldNames>true</fieldNames>
 <responseHeaders>false</responseHeaders>
 <requestHeaders>false</requestHeaders>
 <responseDataOnError>false</responseDataOnError>
 <saveAssertionResultsFailureMessage>true</saveAssertionResultsFailureMessage>
 <assertionsResultsToSave>0</assertionsResultsToSave>
 <bytes>true</bytes>
 <sentBytes>true</sentBytes>
 <url>true</url>
 <threadCounts>true</threadCounts>
 <idleTime>true</idleTime>
 <connectTime>true</connectTime>
 </value>
 </objProp>
 <stringProp name="filename"></stringProp>
 </ResultCollector>
 <hashTree/>
 </hashTree>
 </hashTree>
</jmeterTestPlan>
